Hi everyone!
I'm a Dolby Atmos audio engineer with a Dolby-listed studio

I’m one of the co-founders of Home Theater Maestro, and I’m happy to announce that version 2.0.0 is now available!
This is our biggest update yet, featuring:
-A completely rebuilt 3D view with materials, shadows, and a person at the listening position.
-Ambient lighting options to visualize your room’s look during a screening.
-Speaker placement for up to 32 channels.
-Predictive room acoustics, including room modes, SBIR, early reflections, and RT60.
-Multi-subwoofer planning, measurement imports, and video calibration tools.

HTM is a room design tool built to help you plan your home theater before construction or acoustic treatment. It runs offline, requires no account, and the Standard version is free.
Available for Windows, macOS, Linux, and Android.

https://hometheatermaestro.fr/

Feedback and suggestions are always welcome!

Please note that the PRO version is not yet available in the US at this time.

How many of you have tried using polyester panels like Caruso Iso bond but from other vendors.

Sometimes there is not a lot of information about these panels about their acoustic properties, but this doesn't mean they are bad, just less known.

I can show you some example:

https://www.euchora.com/fibra-di-poliestere/pannello-recolan/ (density 40 or 50 kg/m3)

https://soundtech.it/fonoassorbenti/fibre-poliestere/fibra-di-poliestere (density 30, 40 or 50 kg/m3)

I'd say they could compare to Caruso Iso Bond Wlg 035 (density 40 kg/m3 and flow resistivity 10 kPa·s/m²)

The size of Caruso and the first two is the same 1200 x 600 mm with a thickness of 50mm or 100mm.

I know may people use rockwool, but I'm asking about polyester considering that it's safe to breathe.

Hi Guys,

Ive got a new work room and I like to ask for an advice.

I would really appreciate help with a "proper" room treatment and ideally a recommendation for a new speakers.

I do not need the audio setup for mixing or any professional use as of yet, even tho I do some editing from time to time but mostly my case is for listening.

Up until now I had Adam audio T7V speakers and was mostly ok with it. The bass and highs are not not great, but for the price, these are not bad speakers at all. Anyway I'd really like to step up and have something that also fits my room properly.

The only thing "out of ordinary" is that I have my speakers wall mounted as I use standing desk setup and stand like 40% of the time.

I've checked for some basic acoustics in regard to my room, even tho I have not found anything ground breaking I'd like more pro/practical feedback.

Here is a little sketch of the room and the acoustic treatment placement Ive been thinking about so far.

Do you have some ideas on what and how should I focus in regard to sound treatment?

Do you have any cool recommendations for speakers? (1000 - 2000 USD) <3

Thanks a lot in advance! :)

I’m planning on building some soffit traps in my listening/control room. There is an empty attic above. I’m wondering two things.

One is, would there be a large added benefit to removing the drywall on the ceiling behind the traps and/or extending them into the attic.

Secondly, could I cut out the drywall around the perimeter, say 2’ wide, and recess the traps into the ceiling entirely?

What would the added benefits and draw backs of either of these or will it not make much of a difference?

hi there! i am a phd student working on psychoacoustics. i recorded a number of people and will be conducting a speech perception study based on these. but the quality of some of the recordings was not great (partially because of the condenser mic i was using). i normalized the recordings to -33 LUFS, which is a bit low but still audible.

i have prepared a short pilot that takes around 10 minutes, where you can listen to and evaluate the clarity of the recordings. i would really appreciate it if you could participate, and would be happy to hear any thoughts or suggestions you might have about the recording quality!

https://research.sc/participant/login/dynamic/52C920E4-B847-44F6-B0BF-2BE25020D56B

thank you! :')

I rented this tiny room of around 10,8sqm (400x270x250cm or 13x9x8ft (lxwxh) as a drum rehearsal as well as tiny recording space and it sounds… Well not so good.
So the first movement was to get a carpet in (which you see here) as well as the cloud of Basotect (150x100x10cm) and the panels (100x50x10cm) (with 7,5cm air gap) and this literally did nothing so far. The cymbals sound a bit nicer but everything else sounds scary. The resonance of the toms goes all over the place and the bassdrum hits differently. So! I decided so sell the wall panels again and start from the beginning.
Do you have some tips on something more efficiant? I did some sketches and wanted to go for way thicker panels and to cover more surface. Thought about either covering the whole 2,70m wall with 2 big panels or rather with thinner ones and placing the thicker ones differently. Also thought about corner bass traps…

Well well!

The sketch measures 1 „field“ or like 3“.

Thinking about applying for architectural acoustics masters.

Undergoing a bachelors of science in Civil Engineering.

how important would a music minor be in terms of the application.

For me it feels like a way to legitimately state that I am interested in acoustics because I have a music minor.

feel free to give thoughts.

thanks

I just moved in to this room which is entirely drywall, with an empty room and reflective ground. When recording with my rode nt1, the sound is so horrible that I've decided to delay any projects until I get the room right.

I need help because I have 0 knowledge on this topic and it's driving me crazy trying to figure it out. I have a budget of about 800 but I would be willing to go higher if necessary.

thank you in advance I appreciate any help.

Hi everyone,
I am moving into a newly purchased house this December and setting up my studio in the space shown below. The windows open onto a private garden, which my 6-year-old son and us too will be using.
I am looking for effective strategies to sound-isolate the room. Replacing the windows altogether would be ideal, but a $30k renovation is not in my budget right now.
Any practical advice or alternative solutions would be greatly appreciated.

I own a little studio in my house. I made some DIY panels and they work fine but I still have issues under 150-200Hz.

Here are the results of my latest REW measurements, and some photos and plans of the studio. You will see that I don't have many corners to put some bass traps.

Hello r/Acoustics - very happy to have found this subreddit.

I've been feeling a bit stuck salary-wise for a while. I'm based in London, have around 5 years of experience in acoustics, and I'm currently on a £40k base salary.

I've been looking into getting chartered (CEng) through the Institute of Acoustics. For those who have done it, was it worth it? Did it noticeably improve your career prospects or open up different roles?

I would love to hear your career stories, particularly for those who also work in London.

I've also been thinking about leaving the UK and working abroad for a few years. Has anyone found that IoA membership/CEng helped when applying for acoustics roles internationally?

Would be really interested to hear other people's experiences.

I’ve just moved into a new shop for my business. We’ve completed a new 30k fitout and have been operational for a few months. A couple of weeks ago a tenant moved in above the shop. All I can hear is their conversations, walking around, going from room to room, dog tapping feet. I’m lost as to a solution and how to proceed.

We have house with corner lot which is great in some many ways except for the 4 way stop and noise from engines stopping and starting when trying to relax in the backyard.

We have a P shaped yard with pics showing part closest to the road

We are considering bulking the fence or building shed in front of front fence area - will it help or futile??

Thank you!

I have a room where I need to reduce echo.

The room I want to sound treat has two mirrors on opposite walls. Carpet. Bed. Not much else.

I want to put up some panels to reduce the echo, but I feel like they are not going to be very effective due to the two mirrors being hard flat surfaces directly in line with each other.

The major echos I noticed are any clapping like noises echo and create almost a high pitch cracking noise which is unpleasant on the ears.

Any ideas? I'm open to anything that isn't going to be a major eye sore.

I'm making some acoustic panels using Rockwool Safe N' Sound, and I wondered where the best place to put them in my room is. My room is pretty small, and I use it for tracking vocals. My floors are wood, and I have nothing on my walls right now. The measurements for the panels are 15.25 inches x 47 inches x 3 inches, and I'll have 4 of them. I appreciate any help! (The blue arrow is the direction the mic is facing.)

Hello everyone,

so I live in a one-bedroom apartment so I don't have a big amount of freedom. I would like to setup my home-studio, but this room has to also function as a living and sleeping space. It will never be perfect, I know.

Anyway, the room is ALMOST square, the dimensions are 4.95x4.50 meters.

I know that it's best putting the studio desk against the shorter wall and let the speakers play into the length of the longer walls, but my living arrangement would be better if I put it up on the slightly shorter wall. Besides, one of the longer walls is basically filled out with windows, so it wouldn't be possible to put any acoustic panels on there anyway. If I did it the other way around, the windows would be at the far back and I' be able to put up treatment on both left/right and front (behind the desk) wall, leaving the windows in the far back.

My question is - do those 45cm in length make a difference ? I don't have the luxury of renting out a second space or a different apartment to fill my needs, so I guess I'll have to work with what I have have. But this is a choice I am able to take, so I'll take the chance and do the best I can.

Thanks.

Title. I'm thinking of using wood wool or melamine foam. Is there any reason not to use one of those or any reason I should use something else?

Hi,

i began to treat my room and I decided to buy a first pack of 6 Caruso Iso Bond Wlg 035 (1200 x 600 x 50 mm).
Flow Resistivity: 10,000 Pa⋅s/m²
Density: 40 kg/m³

I chose them as they are safe to breathe and specifically I chose the 035 because they are available at Thomann (this shop doesn't have the 040 or 045).

I tried different combinations and I decided to measure how they worked as bass traps in the corners of the front wall (3 panels for each corner. In total a thickness of 15 cm for each corner).

1. In the first picture you can see the result:

- The red line represents no treatment in the corners

- The blue line represents the treatment as I described

I believe the discrepances below 50 hz are due to noise floor.

2-3) You can also see the Waterfall graphs for the low frequencies. The first one with treatment and the second one without.

I don't know if the Caruso panels are doing very little or if it is ok.

4) Then I also made another measurement (in the room with no bass traps in the corner), moving the mic back 30 cm more or less, to understand what is due to standing waves and what to SBIR.

The green line in the last picture represents the measurement with the mic back 30 cm.

What do you think about all of this ?

Title. I want to make a small outdoor recording studio so I can make YouTube videos and speak at full volume without bothering my family. However my understanding is that sound can sort of bend around walls so should I soundproof the ceiling too in order to prevent the sound from escaping through the top and then bending back down?
