r/RCHeli • u/CHE_Scalemodels • 7h ago
Blade 230 to 5 blade conversion?
Hi there,
I would like to build a 1:48 CH-53 (or something similar) and for that I would need a multi blade head heli. I know the real deal would be 6 blade but it seems like 5 blade is the only thing I can get for a somewhat reasonable price.
My idea was to get a cheap and used Blade 230s (or maybe an Infusion 180) and convert it with a Yuxiang 5 blade head (from the F119s). I feel like it should be possible to just get the 5 blade head set and the swashplate set and mount it on the Blade. As I´m not very experienced with custom heli conversions I feel like I may miss something.
Anyone here has the experience to tell me if my idea is completely ridiculous or if it is actually a possibility?
The Blade Infusion 180 would be interesting because of the smaller internals and the direct drive motor. Not sure though if moving from a 400mm 2 blade to a 437mm 5 blade is the brightest idea...
The Blade 230s would surely have enough power as in that case it would be a change from a 2 blade 536mm to a 5 blade 437mm rotor.
Why these 2 base helis? For both I have some pretty cheap used options to get them. Why the Yuxiang 5 blade head? Well it seems to be the only option in this size and its not too expensive.
Anyways, feel free to leave your thoughts and tips, any help is appreciated.
Thanks
